Hytera BP565 DMR UHF vysielačka

Kód: BP565U1
Novinka
Značka: Hytera
232,58 € 193,82 € bez DPH
Na objednávku

Detailné informácie

Certifikovaný predajca
Certifikovaný predajca
Motorola, Caltta, eChat, SDRplay, Expert Electronics
Doručenie do 2 dní
Doručenie do 2 dní
v rámci Slovenskej republiky
Osobný odber
Osobný odber v Košiciach
Možná platba kartou
Poštovné zdarma
Poštovné zdarma pri objednávke
do SR nad 300 €
do ČR nad 400 €

Podrobný popis

The Hytera BP565 UHF DMR handheld transceiver has 128 programmable channels supporting digital and analogue modes. The unit is programmable between 400-470MHz and it is compatible with existing digital and analogue systems and terminals. Thanks to USB-C connectivity, the 1500mAh Li-ion battery can be charged to 100% in 1.8 hours.

DIGITAL AND ANALOG COMPATIBLE

Supports both digital and analog modes, compatible with your existing digital and analog systems and terminals. Powerful digital features like priority interrupt, basic encryption, text messaging, roaming will enhance your business service. The BP5 series has extended range in class and features 128 channels, making group communication more flexible.

STURDY BODY

Wear-resistant and scratch-resistant body, standard IP54 dustproof and waterproof; large key design, flexible operation even with gloves.

CLEAR AND LOUD AUDIO

Light and compact with a built-in intelligent noise reduction algorithm, to eliminate unwanted background noise, supports three-level noise reduction adjustment so even if the other party is speaking in a noisy environment, you can still listen clearly. 3W high-power loudspeaker with a loudness of up to 90dBA, the sound is clear and loud even in noisy and other harsh conditions; good howling suppression ability, even if many people use the walkie-talkie in the same room, there will be no annoying howling sound.

VOICE BROADCAST

Voice broadcast confirms the operation of programmable buttons or changing the channel of non-display radios.

EXPAND COVERAGE

The Hytera BP565 has a high sensitivity receiving module and high-efficiency monopole antenna to enhance signal penetration and achieve better call affect even in weak signal areas. In addition, the monopole antenna has a unique thick screw thread design and is not easy to break and bend, it helps to enhance antenna life time and also increase the radiation efficiency compared to traditiona.

Type-C CHARGING

Use Type-C charging interface, can be used with a mobile power supply to instantly replenish energy, and put it to work anytime, anywhere.

HIGH ENERGY BATTERY

The BP5 series uses international well-known brand batteries with a long service life. It still has 80% of the initial battery capacity after 500 charge-discharge cycles. The radio can be charged from 0% to 100% in only 1.8 hours. After charging for 1 hour it can work for 10 hours. A 10W rapid-rate charger ensures safe and reliable charging which can work in harsh environments such as high or low temperatures.

DELICATE APPERANCE

Lightweight design making it lighter and thinner than similar products, easy to carry and use: Two-colour injection moulding making it highly recognisable and able to suit the user’s working environment and dressing habits. The colour can be flexibly customised based on your requirement.

TRUSTWORTHY QUALITY

Hytera has the world’s largest professional communication production line, and manufactures each walkie-talkie in accordance with Industry 4.0 standards. Our strict supplier management system certification ensures each component meets the quality control requirements to ensure the consistency of product quality.

EXCELLENT COVERAGE

The Hytera BP565 has a high sensitivity receiving module and high efficiency monopole antenna to enhance signal penetration and achieve better call affect even in weak signal areas. In addition, the monopole antenna has a unique thick screw thread design and is not easy to break and bend, it helps to enhance antenna life time and also increase the radiation efficiency compared to traditional antennas by 10% to extend radio communication distance.

Hytera BP565 box contains:

  • Hytera BP565 Radio
  • Li-ion Battery (1500mAh)
  • Desktop Charging Dock
  • UK & EU standard power adapter
  • Standard UHF or VHF Antenna
  • Nylon Strap
  • Belt Clip
  • User Manual
SPECIFICATIONS
Frequency range UHF:400-470 MHz
Channels & zones
Channel capacity 256
Zone capacity 8
Channels per zone 16
Channel spacing
Analogue 12.5kHz/20kHz/25kHz
Digital 12.5kHz
Operating voltage 7.4V
Battery 1500 mAh (standard)
Battery life (5/5/90 duty cycle, high TX power) Analogue:12 h (1500 mAh) / 16 h (2200 mAh), Digital:17 h (1500 mAh) / 23 h (2200 mAh)
Frequency stability ±0.5 ppm
Antenna impedance 50 Ω
Dimensions (H x W x D) 115 mm x 54.5 mm x 29.5 mm
Weight (with antenna & battery) 230g
Display 1.77 inch TFT
Receiver Sensitivity
Analogue 0.18 μV (12dB SINAD)
Digital 0.18 μV / BER5%
Adjacent channel selectivity TIA-603:60 dB @12.5 kHz / 70 dB @20/25 kHz, ETSI:60 dB @12.5 kHz / 70 dB @20/25 kHz
Intermodulation TIA-603:70 dB, ETSI:65 dB
Spurious response rejection TIA-603:70 dB, ETSI:70 dB
Blocking TIA-603:80 dB, ETSI:84 dB
Hum and noise 40 dB @12.5 kHz, 43 dB@20 kHz, 45 dB@25 kHz
Rated audio power output 1W
Rated audio distortion <3%
Audio response +1 to -3dB
Conducted spurious emission <-57 dBm
Transmitter RF power output, UHF:4W / 1W, VHF:5W / 1W
FM modulation 11 K0F3E @12.5kHz, 14K0F3E @20kHz, 16K0F3E @25kHz
4FSK digital modulation 12.5 kHz data only:7K60FXD, 12.5 kHz data and voice:7K60FXW
Conducted/radiated emission -36dBm @<1GHz; -30dBm @>1GHz
Modulation limiting ±2.5kHz @12.5kHz; ±4.0kHz @20kHz; ±5.0kHz @25kHz
FM hum & noise 40dB @12.5kHz; 43dB @20kHz; 45dB @25kHz
Adjacent channel power 60dB @12.5kHz; 70dB @20/25kHz
Audio distortion ≤3%
Environmental
Operating temperature -30°C to +60°C (radio only / battery:-20 ℃)
Storage temperature -40°C to +85°C
ESD IEC 61000-4-2 (level 4), ±8 kV (contact), ±15 kV (air)
Ingress protection IEC60529-IP54 (IP67 optional)
Humidity MIL-STD-810 H
Shock and vibration MIL-STD-810 H
